Mecer 2KVA Line Interactive UPS ( ME-2000-VU)

Description

Specification

Body.

• Dimensions (Maximum Height x Maximum Width x Maximum Depth): 205mm, 20.5CM x 146mm, 14.6CM x 397mm, 39.7CM
• Weight: 11.5 KGs

Outputs.

• AC Voltage Regulation (Batt. Mode): ± 10 %
• Frequency Range (Batt. Mode): 60 Hz or 50 Hz ± 1 Hz
• Transfer Time: 2 – 6ms, 10 ms max
• Waveform (Batt. Mode): Simulated Sine Wave

Inputs.

• Capacity: 2000VA / 1200W
• Voltage: 110/120 VAC or 220/230/240 VAC
• Voltage Range: 81-145 VAC or 162-290 VAC

Communications and management.

• Control panel: LED status display with On-Line; On Battery; Replace Battery and Overload indicators
• Audible Alarm: Alarm when on battery; distinctive low battery alarm; overload continuous tone alarm

Environmental.

• Operating Temperature: 0 – 40 °C
• Operating Relative Humidity: 0 – 90% non-condensing %
• Noise: 40.0 dBA
